Stirotermal system panels

Stirotermal Duo 11 is a very compact panel, which allows a uniform load of up to 3000 kg/m². It consists of hard polystyrene and a hard corrugated polystyrene film. The panels join solidly and waterproof with each other longitudinally and transversely according to the principle “knob into knob”, therefore they are suitable for installation under … Continued

Stirotermal Duo 20 is a very compact panel, which allows a uniform load of up to 3000 kg/m². It consists of hard polystyrene and a hard corrugated polystyrene film. The panels join solidly and waterproof with each other longitudinally and transversely according to the principle “knob into knob”, therefore they are suitable for installation under … Continued

Stirotermal Duo 30 is a very compact panel, which allows a uniform load of up to 2400 kg/m². It consists of hard polystyrene and a hard corrugated polystyrene film. The panels join solidly and waterproof with each other longitudinally and transversely according to the principle “knob into knob”, therefore they are suitable for installation under … Continued

Stirotermal Solo is a thermoformed panel with knobs, made from hard polystyrene film in a thickness of 1 mm. The shape of the knobs allows for a very firm grip of pipes in diameter of 14 to 18 mm at an interval of at least 50 mm. It is ideal for installations in renovations, where … Continued

Stirotermal Dry is a board of expanded polystyrene (EPS) with grooves for the heating pipes. The board is intended for dry installation of floor respectively wall heating in residential and commercial premises. Prior to installation of the heating pipes, radiation sheets are inserted into the grooves of the board which allow heat transfer to the … Continued

Stirotermal Silent Reflect is a panel, which besides appropriate thermal insulation also provides insulation against impact sound whose level is reduced by 28 dB. Made of elasticated styrofoam and vacuum-coated in silver metallized PE film. It has knobs of octagonal and conical shape, which enable easy installation of pipes with diameters of 16 to 20 … Continued

The boards STIROTERMAL BASIC 30 are produced out of harder EPS and are vacuum-coated with a blue PE film. Octagonal conical naps enable the installation of pipes with diameters of 16 to 20 mm at an interval of at least 7.5 cm; additional attachment of the pipes is not necessary. The special shape of the … Continued

The heat transfer metal sheet is made of galvanized steel sheet. The sheet has a channel that is adapted for mounting tubes of diameter 16 mm.

The EPE perimeter strip is made of expanded polyethylene of closed cell structures. It is used to prevent the dispersal of impact sound at the joint screed – wall. The partially self-adhesive back side easily glues to the wall, an additional polyethylene tape prevents the swelling of the screed between edge strip and system panel.
